Jinhua Hepan Bridge

Innovative design for an architecturally distinctive cable-stayed vehicle and pedestrian bridge across the Jinhua River, Zhejiang Province, China.
Sunset view of the bridge design

Services (1)

Sectors

Location

Jinhua City, Mainland, China

Client

Powerchina Huadong Engineering Corporation Limited

Architect

WilkinsonEyre

Cundall was appointed with architects WilkinsonEyre to design a landmark road bridge to meet the needs of Jinhua City’s growing economy and population. Several design schemes were presented to the client and city authorities, who chose to proceed with a 350m long cable stayed bridge with maximum 175m span, featuring an elegant 60m tall central V-shaped pylon. This design picks up a 50m wide steel box girder deck via inclined stay cables.

We developed numbers of schemes through a parametric approach to achieve a balanced design both structurally efficient and aesthetically appealing within tight programme. For the scheme chosen by the client, further detailed study was carried out to optimise the cable pre-stress in conjunction with pylon and deck size while meeting the essential structural performance and aesthetic criteria.

"Using parametric approach to support our design approach enabled rapid response to design changes and optimisation of the outcome through exploration of a large pool of solutions. The final structural design incorporates prestressed cables, so there is a complex interplay of forces at work. The Jinhua Hepan bridge takes this complexity one step further due to its featured slender and split pylon." Dong Chen, Director.

Key fact

The clear bridge span on each side of the pylon is approximately 135m.

1/3

Key fact

Pedestrians are safely separated from vehicles via strategically positioned cables inset from the deck edge.

2/3

Key fact

Cable placement decreases the design stress in decks and pylon, allowing for smaller cross-sections and a lighter, elegant, slender-looking bridge.

3/3

Dong Chen in black jumper with office wall background

Dong Chen

Director, Structural Engineering

View bio

Any cable-stayed bridge demands a delicate balance of the interlaced relationship of geometry and forces.
