Steps to Net Zero: Step 4 – Provide onsite renewable energy and storage where possible
Simon WyattView bio
Most businesses have historically started and ended their net zero carbon journey by buying “green” electricity and assuming that they have done their part. This sadly is shutting the stable door after the horse has bolted.
Simply, if everyone tried to purchase green electricity there wouldn’t be enough. In the UK about 20% of electricity is supplied from renewable sources, the majority of the rest is still supplied by fossil fuels. Even if we were able to maximise the UK’s renewables potential and generate 374tWh of green electricity per year, it would only equate to 40% of the current UK consumption (see figure 1 from the UKGBC).
This clearly demonstrates the need for energy intensity targets and why they are so vital to the UK meeting its net zero carbon targets. The energy intensity targets are set to consider how much green electricity will be available in 2050 for each building to enable the grid to be 100% “green”. If we exceed these targets, then there won’t be enough electricity for everyone else. We need to start seeing electricity as a limited resource in need of conversing. That is why steps one, two and three of our net zero carbon strategy are so important before we even consider where are energy comes from.
You could argue that if you were able to meet all your electrical demands on site with your own onsite renewable technologies then it doesn’t matter how much energy you use. But this ignores the simple facts:
- most buildings do not have the potential to provide enough electricity to meet their own requirements. i.e. they don’t have enough roof area for solar collectors.
- this is also a matter of resource efficiency, if you are using more than your fair share of resources then somewhere someone else is having to make up for it or go without.
In terms of onsite renewable generation, buildings which are said to be self-sufficient and “zero energy” are typically low-rise buildings in rural or semi- rural environments. They are normally one or two stories high and have enough roof space to accommodate a solar PV array large enough to meet their own demands. This is great but you could argue that all rural buildings should be built this way, especially when you consider the transport emission associated with traveling to and from these more remote buildings. The problem is in dense urban environments where buildings are much higher. In these instances, it is not possible to meet all or even a significant proportion of their electrical requirements from onsite renewable technologies. They must look to offsite.
In terms of off-siting renewable energy there are a range of options all with their own complications:
- Have your own offsite solution: several large organisations have bought their own wind turbines or wind farms and used the electricity generated to supply their buildings and business. This is probably the best form of off-siting, but it obviously relies on buying power and size. For those of us who cannot afford to buy their own wind farm there are a number of community schemes which provide scalable solutions. But it isn’t as simple as saying that if over the course of a year you consume 100MWh then all you need to do is generate 100MWh to be net zero. As your consumption and generation are unlikely to be aligned, meaning you will still be reliant on the grid for part of the year. So, you will need to factor in transmission losses and the embodied carbon of the grid itself. It also beggars the questions of what happens when it isn’t windy? You obviously still need power. This will come from the same grid and typically be provided by a gas-fired power station.
- Purchasing “green” electricity; in the UK this isn’t as easy as it sounds. There are multiple shades of “green” electricity. Some suppliers like ‘Bulb’ or ‘Good Energy’ only provide electricity to the grid from renewable technologies. But some of the bigger utility companies claim to provide 100% “green” electricity despite owning gas and coal fired power stations. The way they do this is that in the UK all suppliers are required by law to provide a percentage of their electricity from renewables. So, if a customer asks for a “green” tariff they simply proportion a percentage of their green electricity to them. But there is so little demand for “green” tariff in the UK that most suppliers have a surplus. They are therefore free to sell the green certification for this surplus to other suppliers who are able to attach the green certification to their dirty electricity and sell it as green! We therefore recommend that people carefully look at where their electricity really comes from and try and buy from suppliers who only own renewable generation plant, as this will stimulate the production of more green electricity. This still has the same problem as outlined above in that if it’s not sunny or windy enough to meet demand you will still be taking electricity from the grid and it will most likely be coming from a gas fired power station. So, it would wrong to use a zero-emission factor, you should still be using the grid average.
- Off-site renewables using PPA: Power purchase agreement (PPA) or electricity power agreement, is a contract between two parties, one which generates electricity (the seller) and one which is looking to purchase electricity (the buyer). PPAs are a way for corporate buyers to purchase power and renewable certificates directly from an energy generator, rather than the local utility, enhancing their green credentials. This is a halfway house between the other two options and generally comes at a cost premium than buying from a green traffic, but still has the above draw backs.
So, in summary, we must set and achieve energy intensity targets for all buildings (new and existing) to enable us to meet the entire national electricity demands by renewable sources. In rural or semi rule location all buildings should generate more electricity than use whilst taking account grid losses and embodied carbon. Local storage should be used to level and peaks and provide demand control. In urban areas buildings would be designed to be as low energy as possible and only then look to provide that electricity from clean renewable sources. Ideally directly from their own or a community supply if not from a third party supply with only renewable energy generation plant.
The University of Wollongong’s Sustainable Buildings Research Centre (SBRC) is designed to be a living laboratory Case study. The centre will test a range of existing sustainable building technologies, whilst researching and developing new products in conjunction with industry partners.
As well as targeting a 6 Star Green Star Design rating, the Sustainable Buildings Research Centre is the first Australian building to be certified by the Living Building Challenge, the world’s most advanced measures of sustainability in the built environment. It will produce all its own power on-site from renewable sources, be water neutral, use local resources and eliminate the 14 most common toxic chemicals found in buildings (known as the Red List).
The project comprises a 900 metre square testing facility along with a two-storey office and training wing for researchers, industry collaborators and administrative staff. The testing facility is fully naturally ventilated. It is primarily constructed from re-used bricks that have been locally sourced and heavily insulated to achieve thermal comfort.
The operational energy will be generated using a range of photovoltaic technologies, geothermal and wind energy to achieve zero net energy in operation. All construction and operational embodied energy will be offset onsite using the excess electricity generated by the centre extensive solar array will less than 10 years.
